3 Inch Hydraulic Hose Crimping Machine with 300pcs/h Work Efficiency 4KW Motor Power and 1000T Crimping Force

3 Inch Hydraulic Hose Crimping Machine with 300pcs/h Work Efficiency 4KW Motor Power and 1000T Crimping Force

Nombre De La Marca:	FY
Número De Modelo:	FY-CBK-120C
Cuota De Producción:	1 juego
Precio:	5000
Condiciones De Pago:	LC, D/A, D/P, T/T, Western Union, MoneyGram
Capacidad De Suministro:	300 conjuntos por mes

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Shanghai, China

Certificación:

Documento:

OUR CATALOGUE.pdf

Peso:

1250 kg

Condición:

NUEVO

Dimensión (largo* ancho* alto):

755*1045*1630MM

Garantía:

1 año

Servicio postventa proporcionado:

Soporte técnico de video, soporte en línea

Voltaje:

110V/220V/380V/415V 50/60Hz

Potencia(w):

5,5kW

Fuerza de engasta:

1000T

Color:

Azul/blanco o de encargo

Rango:

6-76 mm, 1/4" a 3'', 1/4''-3''

Nombre del producto:

Máquina prensadora de mangueras hidráulicas de 3 pulgadas con sistema de control PLC Fuerza de prens

Aplicación:

Manguera

Dies gratis:

15 sistemas

Presión nominal:

31.5MPA

Palabras clave:

Máquina que prensa de la manguera hidráulica del PLC

Destacar:

Máquina prensadora de mangueras de 3 pulgadas, Máquina prensadora de mangueras en espiral, Máquina p

Detalles de empaquetado:

Caja de madera estándar de exportación

Capacidad de la fuente:

300 conjuntos por mes

Resaltar:

300pcs/h Work Efficiency Hydraulic Hose Crimping Machine

4KW Motor Power Hose Pressing Machine

1000T Crimping Force Hydraulic Fitting Press

Descripción del producto

3 Inch Hydraulic Hose Crimping Machine with PLC Control System

2800KN Crimping Force | 31.5MPA Rated Pressure | 6-76mm Crimping Range

The 3 Inch Hydraulic Hose Crimping Machine with PLC control system delivers precision, reliability, and efficiency for hydraulic applications. With 2800KN crimping force, 31.5MPA rated pressure, and 6-76mm crimping range, this machine is ideal for automotive, construction, and manufacturing professionals.

Key Features

PLC Control System: Advanced programmable control for precise crimping adjustments and operational efficiency
High Crimping Force: 2800KN capacity for secure high-pressure hydraulic hose connections
Rated Pressure: 31.5MPA operation for demanding applications
Versatile Crimping Range: Accommodates 6mm to 76mm hoses (rubber, thermoplastic, and reinforced types)
Robust Construction: High-quality materials for long-lasting performance in industrial environments

Advantages

Enhanced precision through PLC-controlled crimping for hydraulic system integrity
Increased efficiency with programmable features reducing operational downtime
Versatile applications for both small-scale and large-scale projects
Cost-effective investment combining advanced technology with robust construction
Multiple safety mechanisms for operator and equipment protection

Technical Specifications

Crimping Range	6-76mm (1/4"-3" inner diameter)
Quantity of Dies	15 sets
System Pressure	31.5Mpa
Motor Power	4kw
Voltage Options	110V/220V/380V/415V, 50HZ/60HZ
Crimping Force	2800KN
Work Efficiency	300pcs/h
Machine Dimensions	84010901760mm
Net Weight	1250kg
